High-pressure fuel pump 2503092 Astemo for Audi RS4/RS5 S4/S5, Volkswagen Touareg

The topic that comes up on every RS4/RS5 B9 forum

On the EA839 twin-turbo V6, the mechanical high-pressure pump does its job in stock configuration, but as soon as you touch the ECU map (Stage 2, downpipes, E85), it quickly becomes the limiting factor. Classic symptom: the mixture goes lean under full load, cut-outs or hesitation above a certain engine speed, and a tuning software alarm flagging insufficient rail pressure. Many tuners recommend checking, or even planning to replace, this pump before increasing power, rather than discovering the problem on the dyno.

Why this Astemo pump

Astemo has taken over Hitachi production (same plant, same expertise, simple name change): a new pump with original tolerances, not a remanufactured part. It is the same part fitted as original equipment on RS4/RS5/S4/S5 B9, SQ5 and Q8, a sound choice both as a standard replacement and as a base for tuning.

Key features

• New high-pressure fuel pump, OE supplier quality
• Compatible OEM references: 06M127026H, 06M127026Q, 06M127A01
• Direct fit, no adaptation required

Compatibility

Audi RS4 B9 2.9 TFSI (450 hp), RS5 B9 Coupé/Sportback 2.9 TFSI (450 hp), S4 B9 3.0 TFSI (354 hp), S5 B9 Coupé 3.0 TFSI (354 hp), SQ5 (FYB) 3.0 TFSI (354 hp), A8 50/60 TFSI Mild Hybrid, Q8 55 TFSI Mild Hybrid, VW Touareg III 3.0 TSI 4Motion. Check your exact reference using our vehicle selector.

Hubshop advice

Switching to E85 or preparing a Stage 2 remap? Plan ahead for replacing this pump to avoid fuel supply shortfalls under full load: it spares you plenty of unpleasant surprises on the road or on the dyno.
