MAZDA MAZDA3 BL - Track R3 Dynaparts Coilovers (09-13)

On track, high-speed compression makes the difference in fast corners and late braking. The Track R3 makes it independently adjustable, as well as rebound and low-speed compression. Inverted monotube architecture, twin reservoirs, race-oriented spring rates.

Technical specifications

• Damping adjustment: 3 independent ways, 33 positions per way
• Design: Inverted monotube (upside-down)
• Front strut mount: Ball joint strut mount with aluminum camber plate
• Rear strut mount: Fixed aluminum strut mount (or ball joint type with upcharge)
• Front spring rate: 16 kg/mm
• Rear spring rate: 16 kg/mm
• Separate oil reservoir: Yes
• Additional reservoir: Yes
• Use: Track use only

Vehicle fitment

• Model: MAZDA MAZDA3 BL
• Years: 09-13

Important notes:

• 2WD vehicles including MPS. Supplied with a pair of cables allowing adjustment without disassembly.

Why choose the Track R3?

The Track R3 is the top of the Dynaparts range: triple adjustment, upside-down design, twin reservoirs. It is the kit for drivers with a precise setup in mind. On bumpy tracks or in fast sequences, the adjustable high-speed compression makes a measurable difference in lap times.

For less intensive use, the Track R2 offers the same fundamentals (upside-down, twin reservoirs) with 2-way adjustment. The Street R2 and R3 allow mixed road/track use with the same level of adjustment precision.
