WAGNER Tuning Intercooler Audi S3 8L

Wagner Tuning performance part: front-mount Performance intercooler designed and manufactured in Germany by Wagner Tuning for the Audi S3 8L 1.8T quattro 210 and 225 hp.

From the factory, the Audi S3 8L cools its boost air with two small side-mount intercoolers with a combined volume of only 2.7 L, which saturate very quickly once the 1.8 20V turbo is tuned. The Wagner Tuning kit replaces them with a single large-capacity front-mount intercooler, mounted in front of the radiator and air conditioning condenser: with nearly four times the volume, the intake air stays noticeably cooler, pressure drop is reduced and the engine delivers higher and more consistent power.

Technical specifications:

• Volume of 10.65 L, versus 2.7 L total for the two original side intercoolers (2 x 174 x 183 x 85 mm)
• Core dimensions: 600 x 355 x 50 mm
• High-performance core, for cool boost air even in the most demanding conditions
• Aluminum cast end tanks, CAD-optimized and highly pressure resistant, for minimal pressure drop
• Fittings: 60 mm inlet and 70 mm outlet, ideal for a larger diameter throttle body
• Weight: 9.9 kg
• Plug & play fitting: the intercooler mounts in front of the original engine radiator and air conditioning condenser

Kit contents:

• 1 Wagner Tuning Performance intercooler
• 2 silicone hoses
• 4 hose clamps
• Mounting hardware
• 1 installation manual

Fits: Audi S3 8L 1.8T quattro 154 kW / 210 hp (1999-2001, engine codes APY, AMK, AUL) and 165 kW / 225 hp (2001-2003, engine code BAM)

Intended use: motorsport part, not street legal for use on public roads.

Important: Verify that this part fits your vehicle (year, displacement and engine code) before ordering.
